EVISA E25.2 HV

With a Nominal Pumping Speed of 30M³/Hr @ 50Hz 35M³/Hr @ 60Hz

The lubricated rotary vane pumps EVISA are designed to be used in a wide range of industrial and healthcare applications.

They can run continuously from atmospheric pressure to ultimate vacuum.

They are very quiet and extremely robust.

Characteristics

	50 Hz	60 Hz
Nominal Air Flow Rate	30.0M³/Hr 17.7 CFM	35.3M³/Hr 20.8 CFM
Pumping Speed *	28.0 M³/Hr 16.5 CFM	33.6M³/Hr 19.8 CFM
Pumping Speed @ 1mbar Inlet Pressure *	9.8M³/Hr 5.8 CFM	11.7M³/Hr 6.9 CFM
End Vacuum – without Gas Ballast	≤5x10-¹mbar ≤0.38Torr
End Vacuum – with Gas Ballast Open	≤2mbar	≤1.5Torr
Water Vapour Permitted Maximum Pressure *	16.9 mbar	18.7 mbar
Water Vapour Capacity *	0.27 Kg/Hr
Oil Type	MV99S SYNTHETIC OIL
Oil Capacity	1.5l
Noise Level	60db(A)	62db(A)
Motor Voltage 3ph 1ph	230/400V Δ/Y 230V	220/380 230V
Motor Power	0.75KW	0.86KW 1.5hp
Rotation Speed	1500 rpm	1800 rpm
Motor Version	IP55 motor IE2 F-class	IP55 motor F-class
Inlet Connection	1” BSP
Outlet Connection	1” BSP
Weight with Oil	39Kg 86lb
