EVISA E25.R

With a Nominal Pumping Speed of 28M³/Hr @ 50Hz 33M³/Hr @ 60Hz

The lubricated rotary vane pumps EVISA are designed to be used in a wide range of industrial and healthcare applications.

They can run continuously from atmospheric pressure to ultimate vacuum.

They are very quiet and extremely robust.

Technical Characteristics E25.R HV

		50Hz	60Hz
	Nominal Flow Rate M³/Hr - CFM	28 – 16.4	33 – 19.4
	PNEUROP pumping speed M3/Hr - CFM	26 – 15.3	31 – 18.2
	Pumping Speed @ 1mbar inlet Pressure	18.6 – 10.9	20.8 – 12.2
Without Gas Ballast	End Vacuum mbar – Torr	≤6x10^-2 – 4.5x10^-2	≤8x10^-2 – 6x10^-2
Gas Ballast opened 1.5 Rotations	End Vacuum mbar – Torr	≤6x10^-1 – 4.5x10^-1	≤6x10^-1 – 4.5x10^-1
	Water Vapour Max Pressure mbar – Torr	7.3 – 5.5	13.0 – 9.8
	Water Vapour Capacity Kg.h^-1	0.11	0.24

Fully opened gas Ballast	End Vacuum mbar – Torr	≤6.0 – 4.5	≤6.0 – 4.5
	Water Vapour Max Pressure mbar – Torr	130 - 97	180 -135
	Water Vapour Capacity Kg.h^-1	2.1	3.6

Technical Characteristics E25.R

Without Gas Ballast	End Vacuum mbar – Torr	≤2.0 – 1.5	≤2.0 – 1.5
Fully opened gas Ballast	End Vacuum mbar – Torr	≤3.0 – 2.2	≤3.0 – 2.2
	Water Vapour Max Pressure mbar – Torr	88 – 66	114 - 85
	Water Vapour Capacity Kg.h^-1	1.4	2.2

Enquire for Pricing and Availability
