EVISA 300.R

With a Nominal Pumping Speed of 300M³/Hr @ 50Hz, 360M³/Hr @ 60Hz

The lubricated rotary vane pumps EVISA are designed to be used in a wide range of industrial and healthcare applications.

They can run continuously from atmospheric pressure to ultimate vacuum.

They are very quiet and extremely robust.

Single Stage Vacuum Pump with the end vacuum of 6.10×10-² mbar for the E300.R HV
Single Stage Vacuum Pump with the end vacuum of ≤3 mbar for the E300.R
High pumping speed even at low pressure
Integrated Oil Mist Filter on the Exhaust
IE3 Motor
Available in an ATEX compliance version
II 2/2G c,k,b IIB T4 Gb/Gb
II 2/2 D c,k,b IIIC T135°C Db/Db
No INERIS-EQEN: 033438/17

Technical Characteristics E300.R HV

		50Hz	60Hz
	Nominal Flow Rate M³/Hr - CFM	300 – 176.5	360 – 211.8
	PNEUROP pumping speed M3/Hr - CFM	280 – 165	336 – 198
	Pumping Speed @ 1mbar inlet Pressure	171 – 101	205 – 121
Without Gas Ballast	End Vacuum mbar – Torr	≤6.1x10^-2 – 4.5x10^-2	≤6.1x10^-2 – 4.5x10^-2

Fully opened gas Ballast	End Vacuum mbar – Torr	≤2.0 – 1.5	≤2.0 – 1.5
	Water Vapour Max Pressure mbar – Torr	18.6 – 13.9	20 -15
	Water Vapour Capacity Kg.h^-1	2.3	3

Technical Characteristics E300.R

Without Gas Ballast	End Vacuum mbar – Torr	≤3.0 – 2.3	≤3.0 – 2.3
Fully opened gas Ballast	End Vacuum mbar – Torr	≤5.0 – 3.8	≤5.0 – 3.8
	Water Vapour Max Pressure mbar – Torr	13 – 9.7	14 – 10.5
	Water Vapour Capacity Kg.h^-1	1.6	2.0

Measurement according to PNEUROP 6602 specification – 20^oC
