GVPDK5 Two-Stage Rotary Vane Vacuum Pump

Product details

GVPDK5 two-stage rotary vane vacuum pump

The Girovac GVPDK5 is an oil-lubricated, two-stage rotary vane pump with a published pumping speed of 5 m³/h. It is a starting point for compact laboratory and backing-pump enquiries; selection depends on working pressure, gas load and the exact pump version.

Choose by working pressure and evacuation time

Nominal pumping speed does not mean the pump moves the same volume at every inlet pressure. Give us the vessel volume, required pressure, target pump-down time and any continuous gas or vapour load. For a turbomolecular system, the backing pump must also satisfy the turbo manufacturer’s foreline and throughput requirements.

Published specification and version checks

For a replacement, send the existing pump nameplate so we can confirm the appropriate configuration. The brochure gives an ultimate-vacuum figure of 6.5 × 10⁻⁴ mbar with gas ballast closed and 6.5 × 10⁻² mbar with gas ballast; its pressure measurement method is not stated, so these values should not be treated as a total-pressure comparison with another pump.

Oil, connections and maintenance

The brochure specifies GVF70 oil, a 500 ml oil charge and an NW25 intake. Confirm the exhaust connection, electrical supply and supplied accessories separately. Check oil condition and service the pump according to its instructions and process history; an oil change alone may not correct wear or contamination.

Use vacuum oils and greases, spares enquiries and workshop servicing to plan support around the complete pump reference.

Measurement and related equipment

A Pirani vacuum transducer can be considered for pump-down monitoring within its measuring range. Check gas dependence, accuracy, connections and the pressure at the point of use. For documented readings, discuss calibration and the required test points.

Questions about the GVPDK5

Can it be used as a turbo backing pump?

It may be considered where its performance meets the turbo’s required foreline pressure and gas throughput. Send the turbo model and process conditions; a nominal flow match alone is insufficient. Read the vacuum selection guides before specifying the combination.

What electrical supply does it need?

The listed electrical configuration is 230 V, single-phase, 50 Hz. Confirm the exact motor plate and available supply in your quotation, especially for an existing pump or a different production version.

What should I send for a replacement or service quotation?

Include the model, serial number, nameplate photograph, process gas, working pressure and fault or replacement requirement. Add the required date and accessories so the scope can be confirmed.

Compare the smaller GVPDK range

GVPDK5 · GVPDK10 · GVPDK20 · CONTVAC catalogue

Technical reference

Source: Girovac GVPDK range brochure, original table on page 1. Contact us for current availability and configuration options.
