GVPSV8
With a Nominal Pumping Speed of 8M³/Hr @ 50Hz 10M³/Hr @ 60Hz
The GVPSV8 were specifically designed for the AC/R sector and for Laboratory applications.This single stage vacuum pump will provide optimal final pressure of 0.1mbar. a coupling drive drive connecting motor to pump ensures a reliable operation, long life and easy maintenance.
Characteristics
Nominal Pumping speed | 8.5 M3/h |
Pneurop Pumping speed | 8.0 M3/h |
Total final pressure (abs) | 0.1 mbar |
Partial final pressure (ABS) (McLeod) | 0.05 mbar |
Final pressure (ABS) with gas ballast | 3.0mbar |
Maximum inlet pressure for water vapour | 40mbar |
Maximum water vapour pumping rate | 0.18Kg/h |
Motor power | 0.37 KW |
R.P.M | 1400 |
Noise level | 52 dB(A) |
Working temperature | 50-55oC |
Oil Type | GVF70 |
Oil Capacity | 0.40 L |
Weight | 12.5 Kg |
