GVPDIF 3A
With a pumping speed of 150l/sec and air cooled.
Characteristics
Pumping Speed | Without Baffle | L/Sec | 150 |
With Baffle | 100 | ||
Ultimate Pressure with Baffle | Mbar | 1.5 x 10-7 | |
Heater Power | 220v 1Ph 450W | ||
Warm up Time | min | 20 | |
Oil Filling | DC704,100cc | ||
Cooling | Air Cooling | ||
Oil Backstream | Mg/cm2/min | 7.5 x 10-4 | |
Inlet Size | VG-80 | ||
Outlet Size | VG-20 | ||
Weight | Kg | 7.5 | |
