SIRELLA SL300.R

Home / Medium Vacuum / Claw Pumps / SIRELLA SL300.R

SIRELLA SL300.R

With a Nominal Pumping Speed of 260M³/Hr @ 50Hz 312M³/Hr @ 60Hz

The oil-less Claw vacuum pumps SIRELLA are designed to be used in a wide range of industrial applications.

They can run continuously from atmospheric pressure to ultimate vacuum.

They are very quiet and extremely robust.

  • Contactless technology
  • Low noise level
  • High efficiency
  • Low exhaust temperature
  • Easy access and low maintenance
  • Compact size
  • PT100 temperature sensor included
  • Compatible with VFC Variable Frequency Converter from 25 – 70 Hz for electricity cost saving

Technical Characteristics

50Hz

60Hz

Nominal Flow Rate M3/Hr - CFM

260 – 153

312 – 183.6

End Vacuum mbar – Torr

50 – 37.5

50 – 37.5

Continuous End Vacuum mbar – Torr

150 – 112.5

150 – 112.5

Gear box oil capacity MB150S 100% synthetic l - qt

1 – 1.06

1 – 1.06

Noise level db(A)

70

72

Inlet Connection

2” BSP

Outlet connection

2” BSP

Weight with oil Kg lb

300 - 662

Motor Power

5.5Kw

6.6Kw

R.P.M

3000

3600

Measurement according to PNEUROP 6602 specification – 20oC

Enquire for Pricing and Availability

01692 403 008
enquiries@girovac.com

Or

Working...
View Basket
Remove from Basket
View Basket
Remove from Basket
Category: Claw Pumps Brand: MIL'S

Related products

  • SIRELLA SL100.RMIL'S

    SIRELLA SL100.R

    With a Nominal Pumping Speed of 90M³/Hr @ 50Hz ...

    View Details
  • SIRELLA SL150.RMIL'S

    SIRELLA SL150.R

    With a Nominal Pumping Speed of 140M³/Hr @ 50Hz ...

    View Details
