Low Vacuum Capsule Gauges
Capsule dial gauges for measuring modest vacuum relative to atmosphere in dry air and gas systems. The finer negative-pressure scale helps where a standard −1 bar dial is too broad.
- Pressure reference
- Relative to atmosphere
- Measuring range
- 0 to −600 mbar gauge
- Dial diameter
- 63, 100 or 160 mm
- Accuracy
- ±1.6% or ±2.5% FSD, depending on model
Price and availability
Tell us the configuration and quantity you need. Include your process requirements if you would like help with selection.
View quote listProduct details
Overview
Capsule dial gauges for measuring modest vacuum relative to atmosphere in dry air and gas systems. The finer negative-pressure scale helps where a standard −1 bar dial is too broad.
Selection and installation
Use this family for dry gases and specify the normal operating depression. Ask about alternative scales, 316 stainless steel wetted parts or IP65 options if the installation needs them.
Questions about this instrument
Is this the same as a 0–25 mbar absolute capsule gauge?
No. This range reads negative pressure relative to the surroundings. An absolute capsule gauge measures residual pressure against an evacuated reference.
Can I request calibration with my gauge?
Yes. Tell us the operating range, required test points and certificate requirement. We will confirm the calibration option for the selected instrument before quoting. Discuss vacuum gauge calibration.
Which related instruments should I consider?
Compare 0–25 mbar absolute capsule gauge and industrial dial gauges. Check the pressure reference, measurement range and output rather than selecting by connection alone.
Where could this instrument be useful in a vacuum system?
Consider the required local vacuum indication when specifying the INDUSVAC centralised vacuum system or a SIRELLA dry-claw pump installation. Select the measuring range and pressure reference for the process, then confirm the connection and all wetted-material requirements. These links help plan an installation; they do not establish a direct-fit replacement.
Specify your requirement
Send the pressure range and reference (absolute or relative), process gas, connection, quantity and required delivery date. Include the existing model or a photograph for replacement enquiries.
Compare vacuum gauge types or enquire about this instrument.
Specifications
| Equipment type | Vacuum gauges & instrumentation / Dial & Capsule Vacuum Gauges |
|---|---|
| Pressure reference | Relative to atmosphere |
| Measuring range | 0 to −600 mbar gauge |
| Dial diameter | 63, 100 or 160 mm |
| Accuracy | ±1.6% or ±2.5% FSD, depending on model |
| Construction | 304 stainless steel case; brass connection; glass window |
| Connection | ⅛, ¼, ⅜ or ½ inch BSP or NPT; bottom or rear |
| Maximum process temperature | 60°C |
| Ingress protection | IP54 |
Calibration and instrument support
Send the gauge model, pressure range and process details for calibration, replacement or compatibility advice.
Before you order
Confirm the range, pressure reference, connection, electrical output and whether cables, a controller or calibration are included.
Availability, lead time and the applicable warranty are confirmed for your quotation. A catalogue listing does not reserve stock.
What to check in your quotation · Delivery · Returns and faults
Enquire about this product
Low Vacuum Capsule Gauges
Prefer to talk? 01692 660 117 · [email protected]
We use your details to respond to your enquiry. Read our privacy policy.
