Dry screw vacuum pumps for suitable industrial applications. Confirm gas load, operating pressure, cooling and electrical requirements for the selected build.
Manufacturer ordering codes are listed below. Price and availability by quotation.
Part of the Leybold LEYVAC B dry screw vacuum pumps family. Compare the range and other model options.
Tell us the configuration and quantity you need. Include your process requirements if you would like help with selection.
View quote listLeybold LEYVAC LV 120 B Dry Screw Vacuum Pump. Dry screw vacuum pumps for suitable industrial applications. Confirm gas load, operating pressure, cooling and electrical requirements for the selected build.
Quote the complete Leybold ordering code when requesting a price. The entries below identify different configurations; voltage, flange, lubricant, cooling and interfaces must match the installation. Availability and supplied equipment are confirmed with the quotation.
| Product code | Manufacturer designation | Configuration detail |
|---|---|---|
| 19200120V30CQV | LEYVAC LV 120 B, 410, 400V | See designation and selected-code documentation |
| 19200120V31CQV | LEYVAC LV 120 B, 410, 200V | See designation and selected-code documentation |
The following manufacturer data applies to LEYVAC LV 120 B, 410, 400V (19200120V30CQV). Other ordering codes can have different specifications.
| Connection Inlet Flange | DN 63 ISO-K |
|---|---|
| Connection Outlet Flange | DN 40 ISO-KF (NW40) |
| Cooling Method | Water Cooling |
| Power Supply Voltage | 3Ph 380-420V 50Hz; 440-460V 60Hz |
| Power Total Rated | 3700.00 W |
| Pumping Speed Air Nitrogen | 0.028 m³/s |
| Pressure Ultimate | 1.00 Pa |
Send the required product code, quantity, electrical supply and application details. For replacement equipment, include the complete model and serial number. Girovac can confirm the configuration, accessories, price and lead time.
| Manufacturer | LEYBOLD |
|---|---|
| Equipment type | Dry Screw Vacuum Pumps |
| Ordering options | 2 manufacturer codes — see configuration table |
Send the pump model and part number when asking about a replacement. Compatibility depends on the equipment and operating conditions.
Confirm the exact version, electrical supply and connections. Ask whether oil, filters, fittings, cables or controllers are included or separately specified.
Availability, lead time and the applicable warranty are confirmed for your quotation. A catalogue listing does not reserve stock.
What to check in your quotation · Delivery · Returns and faults
Leybold LEYVAC LV 120 B Dry Screw Vacuum Pump
Prefer to talk? 01692 660 117 · [email protected]
We use your details to respond to your enquiry. Read our privacy policy.
LEYBOLD
LEYBOLD
LEYBOLD
LEYBOLD
Compare the stated conditions as well as the values. A missing specification is not a zero rating; confirm suitability with Girovac.
