MIL’S ARICA 12V Oil-Free Rotary Vane Vacuum Pump
The ARICA 12V is a compact dry rotary vane pump for equipment and industrial vacuum duties. The manufacturer catalogue gives 10 m³/h nominal flow at 50 Hz and 150 mbar absolute end vacuum. Match the operating pressure and motor supply to the machine.
Part of the MIL’S ARICA oil-free rotary vane pumps family. Compare the range and other model options.
- Electrical supply
- Confirm voltage, phase and frequency for the motor ordered
- Nominal flow, 50 / 60 Hz
- 10 / 12 m³/h
- End vacuum
- 150 mbar absolute at 50 / 60 Hz
- Motor power, 50 / 60 Hz
- 0.37 / 0.45 kW
Price and availability
Tell us the configuration and quantity you need. Include your process requirements if you would like help with selection.
View quote listProduct details
MIL’S ARICA 12V Oil-Free Rotary Vane Vacuum Pump
The ARICA 12V is a compact dry rotary vane pump for equipment and industrial vacuum duties. The manufacturer catalogue gives 10 m³/h nominal flow at 50 Hz and 150 mbar absolute end vacuum. Match the operating pressure and motor supply to the machine.
Catalogue specifications
| Specification | Details |
|---|---|
| Nominal flow, 50 / 60 Hz | 10 / 12 m³/h |
| End vacuum | 150 mbar absolute at 50 / 60 Hz |
| Motor power, 50 / 60 Hz | 0.37 / 0.45 kW |
| Dimensions | 429 × 206 × 189 mm, catalogue configuration |
| Mass | 16 kg, catalogue configuration |
| Electrical supply | Confirm voltage, phase and frequency for the motor ordered |
These figures are from the February 2022 manufacturer catalogue. Confirm the current motor, connection sizes and installation drawing with the quotation. Nominal flow is not the available flow at every pressure, and the pump’s end vacuum is not a guarantee of pressure in the connected machine.
Choosing the configuration
ARICA dry vanes avoid oil in the pumping chamber. The catalogue permits continuous operation between atmosphere and the stated end vacuum. Select inlet protection for the air stream and maintain the vanes and filters to the manufacturer schedule. Do not assume liquid or corrosive-gas compatibility.
Manufacturer download
MIL’S industrial catalogue, February 2022 (PDF) — PDF page 15, printed page 14.
Selection and support
Explore the ARICA range and MILS brand guide. Compare vacuum gauges and controllers, plan gauge calibration, or discuss servicing.
For MIL’S ARICA 12V Oil-Free Rotary Vane Vacuum Pump, include working pressure, required flow or chamber volume, gas and vapour load, operating hours, electrical supply and connections. For a replacement, send the complete nameplate and serial number so the configuration can be checked.
Specifications
| Manufacturer | MIL'S |
|---|---|
| Equipment type | Carbon Vane Pumps |
| Electrical supply | Confirm voltage, phase and frequency for the motor ordered |
| Nominal flow, 50 / 60 Hz | 10 / 12 m³/h |
| End vacuum | 150 mbar absolute at 50 / 60 Hz |
| Motor power, 50 / 60 Hz | 0.37 / 0.45 kW |
| Dimensions | 429 × 206 × 189 mm, catalogue configuration |
| Mass | 16 kg, catalogue configuration |
Parts, consumables and workshop support
Send the pump model and part number when asking about a replacement. Compatibility depends on the equipment and operating conditions.
Before you order
Confirm the exact version, electrical supply and connections. Ask whether oil, filters, fittings, cables or controllers are included or separately specified.
Availability, lead time and the applicable warranty are confirmed for your quotation. A catalogue listing does not reserve stock.
